Ballast Bypass Type B

EarthTronics logo

Specifications

2000 Lumen, 14.5 Watt, Type B, Color Selectable, 48 inch with Emergency Back-up

Model No. LT812CCTBEM
Order Code: 11735

Quick Specs

Watts: 14.5
Voltage: 120-277V
Operating Temp. Range: -20°C to 45°C
Color Temperature: Selectable 3500K, 4000K, 5000K
Lumens: 2000
Dimming: 0-10V
Power Factor: ≥ 0.9
Rated Life: 50,000 hours

Agency Approvals

UL Listed, FCC Listed, Title 20, RoHS Listed

Product Details

EarthTronics Type B lamp is designed with an integrated emergency driver and eliminates the need for a separate emergency back-up. This 14.5 watt lamp is a replacement for a 32 watt florescent tube and provides 2000 lumens. This Type B can be direct wired quickly. This lamp is color selectable, offering 3  choices 3500K, 4000K, or 5000K which can be adjusted in the field by just sliding the switch to your desired color. When in emergency mode, the driver provides 90 minutes of backup light producing 500 lumens at 3.5 watts. This provides exceptional LED lighting with reduced energy and maintenance costs. This lamp also works in dry or damp locations and enclosed fixtures. The beam angle provides a wide distribution pattern and is perfect for directing more light to the working surface from existing troffer fixtures and strip fixtures as well as task and display lighting applications. Perfect for replacement of T8 fluorescent tubes. This lamp is engineered for high lumen maintenance over its 50,000 hour rated. UL924 Emergency Lighting certified. 120/277V operation.

Order Code 11735 | Model LT812CCTBEMVIEW   DOWNLOAD   EMAIL
